Model: CRA225
Manufacturer: OMVE - Netherlands
The CRA225 unit is an aerator, continuous ice-cream freezer, and crystallizer in one. The system can be executed with an air injection unit, a mixing head, pinworker, scraped surface heat exchangers (SSHEs) and resting tube, ensuring maximum flexibility for your application lab. Our crystallizer can be used to produce mousses, ice cream, spreads, whipped cream, cream cheese, margarine and butter, and other products – all with the same machine.
CRA225 Crystallizer
Model: CRA225
Manufacturer: OMVE - Netherlands
Product Description:
The CRA225 unit is an aerator, continuous ice-cream freezer, and crystallizer in one. The texture of your final product is dependent on three factors: the degree of crystallization, the level of aeration and the mechanical force/shear during processing. The system can be executed with an air injection unit, a mixing head, pinworker, scraped surface heat exchangers (SSHEs) and resting tube, ensuring maximum flexibility for your application lab.
When using the CRA225 for crystallization of oil and fats, the quality of product is based on consistency, structure, plasticity and hardness. Meeting these specific conditions is directly dependent on the recipe and the process equipment. As the recipes and processes are unique for each product, it is important to have the most flexibility possible from your crystallizer.
The hygienic design of the system ensures easy cleaning and a minimum risk of contamination during processing.
Features:
Specifications:
| Product code | CRA225 |
| Process flow rates | 10-30L/hr |
| CIP flow rate | 160L/hr |
| System pressures | 25bar(g) [170/360/725psi(g)] |
| Additional CIP pump (optional) | Up to 800L/hr |
| Refrigeration system (external) | -25°C [-13°F] |
| Max. particle size | 4mm |
| Max. rotating speed | 1450 rpm |
| Diameter scraped surface | 65mm |
| Dead volume per barrel | 810mL |
| Pin Worker Rotation Speed | 1200 rpm |
| Continuous Aeration | Flow controlled |
| Overrun | Up to 200% |
| Materials product side | SS316 |
| Blades | Peek (standard) |
| Weights & Dimensions | |
| Weight | 500kg [1102lbs] |
| L x W x H | 1640 x 1150 x 1650mm [64.5 x 45.3 x 65"] |
| Required utilities | |
| Electrical supply | 400V/ 3ph/ 50Hz - 220V/ 3ph/ 60Hz |
| Compressed air | Max. 6bar [87psi] |
| Water | 4bar [58psi] |
| Drains | Required |
