IKA Shakers MS 3 digital

IKA Shakers

Model: MS 3 digital

Description:

Compact, universal small shaker suitable for shaking tasks with all small vessels and microtiter plates

• Wide range of attachments
• Attachment detection
• Timer with countdown function
• Continuous or touch operation (with standard attachment)
• Stable in all speed ranges
• Sturdy zinc die cast casing
• Two operating modes:

Mode A (safe mode with attachment detection)
the maximum speed of 3.000 rpm is only reached with the standard attachment in
touch mode. When using other attachments the speed is limited to 1.300 rpm.
Mode B (without attachment detection)
A speed of 3,000 rpm is possible with all attachments, depending on the application (see accessory list in the manual).

Technical Data:

• Type of movement orbital
• Shaking stroke 4.5 mm
• Permissible shaking weight (incl. attachment) 0.5 kg
• Motor rating input 10 W
• Motor rating output 8 W
• Permissible ON time 100 %
• Speed min (adjustable) 200 rpm
• Speed range 0 - 3000 rpm
• Speed display scale
• Timer yes
• Timer display 7 segment LED
• Time setting min. 1 s
• Time setting range 1 - 999 min
• Operating mode timer and continuous operation
• Touch function yes
• Working with microtiter plates yes
• Number of microtiter plates 1
• Dimensions (W x H x D) 148 x 63 x 205 mm
• Weight 2.9 kg
• Permissible ambient temperature 5 - 40 °C
• Permissible relative humidity 80 %
• Protection class according to DIN EN 60529 IP 21
• Voltage 100 - 240 V
• Frequency 50/60 Hz
• Power input 20 W
• DC Voltage 24 V=
• Current consumption 800 mA

Scope of delivery

• MS 3 digital
• MS 3.1 Standard attachment
• MS 3.3 Universal attachment
• MS 3.4 Microtiter attachment
• MS 1.21 One-hand insert
• MS 1.32 Test tube insert
